Shadowclad® Natural Groove

Shadowclad® Natural Groove is an uncoated panel suitable for staining and painting when used in applications exposed to weather. The Shadowclad Natural Groove product features a 9mm wide, 5mm deep profile every 150mm across the sheet. Shadowclad Natural Groove is designed for use as an exterior cladding and treated to H3.1 (LOSP).

Shadowclad Natural Groove adds the warmth, versatility and durability of wood to any residential or commercial project.

Request a Shadowclad Product Sample Here

Features & Benefits

  • Manufactured from sustainably-grown NZ plantation pine
  • Range of sheet sizes, profiles and finishes for wide design flexibility
  • Compliant with NZ Building Code requirements
  • Vertical shiplap joints for easy and watertight installation
  • Low formaldehyde emission (E0)
  • Available Forest Stewardship Council® (FSC®) certified (FSC® C012019) upon request
  • Band-sawn sheet surface provides a compelling tactile finish
  • Shadowclad exterior cladding system includes a wide range of purpose-designed exterior flashings
  • Shadowclad installation guidelines must be followed. Please refer to the current Shadowclad Specification and Installation Guide

Compliance

Shadowclad is manufactured to meet the requirements of the NZBC Clause B2 Durability. When treated to the required treatment levels prescribed in NZS 3602, it will form part of an Acceptable Solution complying with the requirements of the NZBC (Acceptable Solution B2/AS1, 3.2.1).

NZBC Clause B2 requires claddings which do not form part of bracing to achieve a minimum structural durability level of 15 years.

Range

This section is currently under review - for information on sheet thicknesses, lengths, packs, pricing and availability, please contact your local merchant.

For Specification and Installation Guides and further information on Cavity Construction click the link below:

 Cavity Construction



Information Bulletin

AUGUST 2021 Using Dark Colours with Shadowclad Information Bulletin

This information bulletin has been created to provide further guidance to building owners using dark colours with Shadowclad

MARCH 2021 Shadowclad Maintenance Information Bulletin

This information bulletin has been created to provide further guidance to building owners about the minimum maintenance requirements for Shadowclad products.

MARCH 2021 Shadowclad General Repair and Replacement Guidelines Information Bulletin

This information bulletin has been created to provide guidance to building owners about the general repair and replacement of Shadowclad products. It is not intended as a complete installation guide, or a substitute for professional advice.

MARCH 2021 Shadowclad Additions and Alterations Information Bulletin

Where additions and/or alterations to the building are made that will affect the structural stability of the building, the weathertightness of an elevation, fire safety or other circumstances identified in Schedule 1 of the New Zealand Building Act 2004 a building consent will be required.

MARCH 2021 Shadowclad Cavity Construction Information Bulletin

This information bulletin discusses the reasons for CHH Plywood’s updated advice to specifiers and homeowners that Shadowclad cladding for new builds should only be used over a drained and ventilated cavity.

Cad

SC001

Typical Framing Setout without Battens

SC068

Shadowclad® to brick external junctions

SC067

Shadowclad® to brick internal junctions

SC066

Shadowclad® to brick vertical junctions

SC065

Shadowclad® to solid plaster external junctions

SC064

Shadowclad® to solid plaster internal junctions

SC063

Shadowclad® to solid plaster vertical junctions

SC062

Shadowclad® to Weatherboard vertical junctions

SC061

Shadowclad® to Weatherboard external junctions

SC060

Shadowclad® to Weatherboard internal junctions

SC058

Shadowclad - Detailing for Enclosed Balustrade (Cavity)

SC056

Shadowclad - Junction with Wall for Cantilevered Deck (Cavity)

SC054

Shadowclad - Balustrade to Wall Junction (Cavity)

SC052

Shadowclad - Balustrade to Wall Junction (Cavity)

SC050

Shadowclad - Basic Apron Flashing (Cavity)

SC048

Shadowclad - Mid Floor to Non-Cantilevered Deck (Cavity)

SC046

Shadowclad - Timber Ground Floor to Non-Cantilevered Deck (Cavity)

SC044

Shadowclad - Upper Storey to Masonry Lower Storey (Cavity)

SC042

Shadowclad - Overhangs and Ground Clearances (Cavity)

SC040

Shadowclad - Pipe Penetration (Cavity)

SC038A

Shadowclad - Alternative Soffit Detail (Cavity)

SC038

Shadowclad - Soffit Alternative Detail (Cavity)

SC036A

Shadowclad - Alternative Soffit Detail (Cavity)

SC036

Shadowclad - Soffit Detail (Cavity)

SC034B

Shadowclad - Meterbox Horizontal Cross Section (Cavity)

SC034A

Shadowclad - Meterbox Vertical Cross Section (Cavity)

SC032

Shadowclad - Window Sill Detail (Cavity)

SC030

Shadowclad - Jamb Detail (Cavity)

SC028

Shadowclad - Window Head Detail (Cavity)

SC026

Shadowclad - Internal Corner with W Flashing (Cavity)

SC024

Shadowclad - Internal Corner with 90-U Flashing (Cavity)

SC022

Shadowclad - External Corner with Cover Boards (Cavity)

SC020

Shadowclad - External Corner with External Box Flashing (Cavity)

SC018

Shadowclad - Mid Floor Horizontal Joint Non Continuous (Cavity)

SC016

Shadowclad - Mid Floor Horizontal Joint (Cavity)

SC014

Shadowclad - Vertical Joint with Top Hat Flashing (Cavity)

SC012

Shadowclad - Nogging for Vertical Cover Batten Between Studs (Cavity)

SC010

Shadowclad - Vertical Joint with Optional Cover Batten (Cavity)

SC008

Shadowclad - Groove Vertical Joint (Cavity)

SC006

Shadowclad - Texture Vertical Joint (Cavity)

SC003

Shadowclad - Fastener Layout

SC002

Typical Framing Setout (with Battens)

Certification

MARCH 2021 Shadowclad Ventilated Cavity Cladding System - BRANZ Appraisal 764

BRANZ appraisal for Shadowclad on a ventilated cavity.

Ecoply & Shadowclad FSC® Certificate

FSC® Certificate for Tokoroa Plywood Mill.

Technical Note

Shadowclad Climate® Ultra Prime

Technical Data Sheet

Shadowclad - Moulds on Plywood

Technical Note relating to moulds on plywood.

Video

Shadowclad Vertical Sheet Joint Groove Profile
Shadowclad Horizontal Continuous Flashing
Shadowclad Mid Floor Horizontal Joint
Shadowclad Vertical Sheet Joint Texture Profile
Shadowclad External Corner Box Flashings
Shadowclad Window Jamb
Shadowclad Overhangs & Ground Clearances
Shadowclad Window jamb & sill
Shadowclad Window Top Flashing
Shadowclad Internal Corner 'W' Flashing
Shadowclad Flashing Junctions & Connections with Horizontal & Back Flashing
Shadowclad External Corner with Cover Boards

Sds

Shadowclad SDS H3.1 LOSP Treated Plywood

Chemwatch Safety Data Sheet.

Shadowclad SDS Untreated Plywood

Chemwatch Safety Data Sheet.

Shadowclad SDS H3.2 CCA Treated Plywood

Chemwatch Safety Data Sheet.

Brochure

Shadowclad Specification & Installation Guide for Mixed Cladding Systems on Cavity Construction

The information in this guide relates to Shadowclad plywood Mixed Cladding Installation for Cavity Construction.

Shadowclad Specification & Installation Guide For Cavity Construction

The information in this guide relates to Shadowclad plywood cladding installation for Cavity Construction.

Building Product Information

Shadowclad® Cavity Construction Product Technical Statement and Building Product Information Sheet

Product Technical Statement and Building Information Sheet for Shadowclad used in Cavity Construction

Case Studies

Shadowclad Carlisle Home Case Study

Shadowclad® Natural Texture Groove by CHH Plywood has been chosen for use in the façades of three new Carlisle Homes – The Jensen, The Pagoda and The Atlantique. Display homes can be inspected on location at Lyndhurst, Cranbourne, Tarneit and Caroline Springs.
